Product Details

Product Specifications

• Adjustable Timing: Yes
• Auto Cutoff: Yes
• BEC: Yes
• BEC Continous Current: 4.5A Continuous
• BEC Maximum Burst Current: 8A Peak
• BEC Type: Fixed voltage, 8A Peak
• BEC Voltage: 5.5V Fixed
• Brakes: Proportional
• Bushing Or Bearing: Bearing
• Connector Type: 6.5mm Bullet
• Forward: Yes
• Input Voltage: 2S (7.4V) minimum, 6S (25.2V) maximum
• Number of Poles: 4
• Outer Diameter: With Fins 1.6 in (41.4mm)
• Product Height: 1.33″ (34mm)
• Product Length: 2.45″ (62.2mm)
• Product Width: 2.20″ (56mm)
• Programmable: Yes
• RPM/Volt (Kv): 60,000 / 2200
• Shaft Diameter: 0.197″ (5mm)
• Shaft Length: 0.79″ (20mm)
• Wire Gauge: 10 AWG
